Commodity Production Costs Report

Ethylene Production from Methane

Ethylene Operating Costs & Plant Construction Costs

1058 kta United States-based plant | 107 Pages | Issue K | Q3 2024
Starting at $799 USD | See Report Editions Prices

This study presents an economic analysis of Ethylene production from methane in the United States using an oxidative coupling of methane (OCM) process. Carbon monoxide is also produced in the process and undergoes methanation, recovering methane.

The report provides a comprehensive study of Ethylene production and related Ethylene production cost, covering three key aspects: a complete description of the Ethylene production process examined; an in-depth analysis of the related Ethylene plant capital cost (Capex); and an evaluation of the respective Ethylene plant operating costs (Opex).

The Ethylene production process description includes a block flow diagram (BFD), an overview of the industrial site installations, detailing both the process unit and the necessary infrastructure, process consumption figures and comprehensive process flow diagrams (PFD). The Ethylene plant capital cost analysis breaks down the Capex by plant cost (i.e., ISBL, OSBL and Contingency); owner's cost; working capital; and costs incurred during industrial plant commissioning and start-up. The Ethylene plant operating costs analysis covers operating expenses, including variable costs like raw materials and utilities, and fixed costs such as maintenance, labor, and depreciation.

Key reference(s): ?

Ethylene Production Cost Report Process Schematic

The process under analysis comprises three major sections: (1) Reactions; (2) CO2 Removal; and (3) Product Separation and Recovery.

Reactions. The methane recycle feed stream, containing CO and H2, coming from the demethanizer head is first heated. This methane stream is then sent to two-stage methanation reactors unit where CO is almost completely converted to methane in presence of hydrogen. The methane stream is mixed with oxygen, undergoing oxidative coupling (OCM) conversion to ethylene. Ethane is injected into the reaction system and is converted in ethylene utilizing the heat generated during methane conversion. Heat is recovered by generating high pressure steam.

CO2 Removal. The outlet stream from the reaction system is cooled and compressed in water quench system , to prevent further reactions and formation of undesirable by-products. Process gas stream is mixed with treated heat natural gas from Desulfurization. The mixed stream is treated in an Amine System to remove carbon dioxide using a Methyl diethanolamine-based unit. The resulting process gas is further treated with a caustic wash to complete remove any existing traces of CO2. The process gas leaving the caustic wash is then dried in a molecular sieve unit.

Product Separation and Recovery. The dried gas is fed to a cold box and cooled to cryogenic temperatures. Condensates from the chilling train are fed to separation columns. In the demethanizer, light ends and hydrogen are stripped off and recycled after treatment, while the bottom stream is fed to the deethanizer. The top stream is fed to an acetylene converter and then fractionated in the C2-splitter. Polymer grade ethylene is obtained as a side stream, and the bottoms stream, containing ethane, is recycled to methanator. The deethanizer bottom stream is fed to a depropanizer, which generates refinery grade propylene in the overheads and mixed C4s in the bottoms.

Report in PDF Format
Download & Explore Anytime
Access in Various Devices
Print & Read Comfortably
Share With Co-workers

Up-to-date Report

Professional report based on Q3 2024 economic data, ensuring timely evaluations.

Multiple Use Cases

Ideal for investment screening, feasibility studies, cost estimates, and research planning.

Proven Methodology

Developed using a consistent methodology honed over a decade, ensuring reliable cost analyses.

Report Editions

Compact



$799

USD

Select

Table of Contents


Features
  • Production Process Information
  • Process Consumptions
  • Labor Requirements
  • Plant Capital Cost Summary
  • Operating Cost Summary
  • Production Costs Datasheet
  • See All Features

 80 Pages | 22 Tables | 9 Images

Read-only Online PDF Format

Updated with Q3 2024 Data

Detailed



$1,599

USD

Select

Table of Contents


Features
  • Production Process Information
  • Process Consumptions
  • Labor Requirements
  • Plant Capital Cost Summary
  • Operating Cost Summary
  • Production Costs Datasheet
  • Plant Capital Cost Details
  • Operating Cost Details
  • See All Features

 90 Pages | 28 Tables | 13 Images

Downloadable PDF Format

Updated with Q3 2024 Data

Most Popular
Premium

Starting at

$2,699

USD

Select

Table of Contents


Features
  • Production Process Information
  • Process Consumptions
  • Labor Requirements
  • Plant Capital Cost Summary
  • Operating Cost Summary
  • Production Costs Datasheet
  • Plant Capital Cost Details
  • Operating Cost Details
  • Plant Cost Breakdowns
  • Plant Capacity Assessment
  • Process Flow Diagrams
  • Costs in Different Countries Add-on
  • See All Features

  • 107 Pages | 34 Tables | 22 Images
  • Print-enabled PDF Format Add-on
  • Updated with Q3 2024 Data
  • Share with Co-workers
  • Technical Support via Email

Content Highlights

Plant Capital Cost Summary

Summary outlining the capital cost required for building the Ethylene production plant examined.

Plant Capital Cost Details

Detailing of fixed capital (ISBL, OSBL & Owner’s Cost), working capital and additional capital requirements.

Plant Cost Breakdowns

Breakdown of Ethylene process unit (ISBL) costs and infrastructure (OSBL) costs; plant cost breakdown per discipline.

Operating Costs Summary

Summary presenting the operating variable costs and the total operating cost of the Ethylene production plant studied.

Operating Cost Details

Detailing of utilities costs, operating fixed costs and depreciation.

Plant Capacity Assessment

Comparative analysis of capital investment and operating costs for different Ethylene plant capacities.

Production Process Information

Block Flow Diagram, descriptions of process unit (ISBL) and site infrastructure (OSBL).

Process Consumptions

Raw materials and utilities consumption figures, by-products credits, labor requirements

Process Diagrams

Process flow diagrams (PFD), equipment list and industrial site configuration
